Jauch Group

Jauch集团是石英晶体、石英晶体振荡器和电池技术的领先专家之一。成立于1954年，我们现在是频率控制产品行业的领先公司之一，也是锂离子和锂聚合物电池未来市场的公认专家。

我们以深入的技术咨询，高应用和认证专业知识，先进的测试环境，高可用性和快速交付产品来强调我们的领导地位。

我们在维林根-施文宁根总部投资了生产设施，以及时满足全球客户的需求。

现代电池装配线为电池解决方案提供高技术要求，确保生产适合各种应用的单个电池组。

我们在子公司Jauch Quartz France, Jauch Quartz uk和Jauch Quartz America的优秀员工开发和销售开创性的技术解决方案。

The Jauch Group is one of the leading specialists for quartz crystals, crystal oscillators and battery technology. Established in 1954, we are now one of the leading companies in the frequency control products industry and a recognized expert on the future market for lithium ion and lithium polymer batteries.

We underline our claim to leadership with our in-depth technical consulting, high application, and certification expertise, advanced test environments, high availability and fast delivery of products.

We have invested in production facilities at our headquarters in Villingen-Schwenningen to meet customer needs around the world in a timely manner.

A modern batteries assembly line for battery solutions with high technical requirements ensures the production of individual battery packs for various applications.

Our competent staff at our subsidiaries Jauch Quartz France, Jauch Quartz United Kingdom and Jauch Quartz America develop and sell pioneering technology solutions.进口晶振

JAUCH原厂编码	生产商品牌	型号	频率	频率容差	频率稳定度	负载电荷	工作温度
Q 0.032768-JTX310-12.5-20-T1-HMR-LF	Jauch晶振	JTX310	32.768kHz	-	±20ppm	12.5pF	-40°C ~ 85°C
Q 0.032768-JTX310-12.5-20-T2-HMR-LF	Jauch晶振	JTX310	32.768kHz	-	±20ppm	12.5pF	-40°C ~ 105°C
Q 0.032768-JTX310-9-20-T1-HMR-LF	Jauch晶振	JTX310	32.768kHz	-	±20ppm	9pF	-40°C ~ 85°C
Q 0.032768-JTX310-12.5-20-T3-HMR-LF	Jauch晶振	JTX310	32.768kHz	-	±20ppm	12.5pF	-40°C ~ 125°C
Q 0.032768-JTX310-12.5-20-T1-HMR-50K-LF	Jauch晶振	JTX310	32.768kHz	-	±20ppm	12.5pF	-40°C ~ 85°C
Q 0.032768-JTX310-12.5-20-T1-HMR-60K-LF	Jauch晶振	JTX310	32.768kHz	-	±20ppm	12.5pF	-40°C ~ 85°C
Q 0.032768-JTX310-7-20-T1-HMR-LF	Jauch晶振	JTX310	32.768kHz	-	±20ppm	7pF	-40°C ~ 85°C
Q 0.032768-JTX310-9-20-T2-HMR-LF	Jauch晶振	JTX310	32.768kHz	-	±20ppm	9pF	-40°C ~ 105°C
Q 0.032768-JTX310-7-20-T2-HMR-LF	Jauch晶振	JTX310	32.768kHz	-	±20ppm	7pF	-40°C ~ 105°C
Q 0.032768-JTX310-9-20-T3-HMR-LF	Jauch晶振	JTX310	32.768kHz	-	±20ppm	9pF	-40°C ~ 125°C
Q 0.032768-JTX310-12.5-20-T2-HMR-70K-LF	Jauch晶振	JTX310	32.768kHz	-	±20ppm	12.5pF	-40°C ~ 105°C
Q 0.032768-JTX310-7-20-T3-HMR-LF	Jauch晶振	JTX310	32.768kHz	-	±20ppm	7pF	-40°C ~ 125°C
Q 0.032768-JTX310-12.5-20-T3-HMR-70K-LF	Jauch晶振	JTX310	32.768kHz	-	±20ppm	12.5pF	-40°C ~ 125°C
Q 0.032768-JTX310-6-20-T1-HMR-LF	Jauch晶振	JTX310	32.768kHz	-	±20ppm	6pF	-40°C ~ 85°C
Q 0.032768-JTX310-6-20-T2-HMR-LF	Jauch晶振	JTX310	32.768kHz	-	±20ppm	6pF	-40°C ~ 105°C
Q 0.032768-JTX210-12.5-20-T1-LF	Jauch晶振	JTX210	32.768kHz	-	±20ppm	12.5pF	-40°C ~ 85°C
Q 0.032768-JTX210-9-20-T1-LF	Jauch晶振	JTX210	32.768kHz	-	±20ppm	9pF	-40°C ~ 85°C
Q 0.032768-JTX310-6-20-T3-HMR-LF	Jauch晶振	JTX310	32.768kHz	-	±20ppm	6pF	-40°C ~ 125°C
Q 19.2-JXS32-10-10/10-WA-LF	Jauch晶振	JXS32-WA	19.2MHz	±10ppm	±10ppm	10pF	-20°C ~ 70°C
Q 19.2-JXS32-12-10/10-WA-LF	Jauch晶振	JXS32-WA	19.2MHz	±10ppm	±10ppm	12pF	-20°C ~ 70°C
Q 19.2-JXS32-8-10/10-WA-LF	Jauch晶振	JXS32-WA	19.2MHz	±10ppm	±10ppm	8pF	-20°C ~ 70°C
Q 19.2-JXS32-9-10/10-WA-LF	Jauch晶振	JXS32-WA	19.2MHz	±10ppm	±10ppm	9pF	-20°C ~ 70°C
Q 20.0-JXS32-10-10/10-FU-WA-LF	Jauch晶振	JXS32-WA	20MHz	±10ppm	±10ppm	10pF	-20°C ~ 70°C
Q 20.0-JXS32-12-10/10-FU-WA-LF	Jauch晶振	JXS32-WA	20MHz	±10ppm	±10ppm	12pF	-20°C ~ 70°C
Q 20.0-JXS32-8-10/10-FU-WA-LF	Jauch晶振	JXS32-WA	20MHz	±10ppm	±10ppm	8pF	-20°C ~ 70°C
Q 20.0-JXS32-9-10/10-FU-WA-LF	Jauch晶振	JXS32-WA	20MHz	±10ppm	±10ppm	9pF	-20°C ~ 70°C
Q 24.0-JXS32-10-10/10-FU-WA-LF	Jauch晶振	JXS32-WA	24MHz	±10ppm	±10ppm	10pF	-20°C ~ 70°C
Q 24.0-JXS32-12-10/10-FU-WA-LF	Jauch晶振	JXS32-WA	24MHz	±10ppm	±10ppm	12pF	-20°C ~ 70°C
Q 24.0-JXS32-8-10/10-FU-WA-LF	Jauch晶振	JXS32-WA	24MHz	±10ppm	±10ppm	8pF	-20°C ~ 70°C
Q 24.0-JXS32-9-10/10-FU-WA-LF	Jauch晶振	JXS32-WA	24MHz	±10ppm	±10ppm	9pF	-20°C ~ 70°C
Q 26.0-JXS32-10-10/10-FU-WA-LF	Jauch晶振	JXS32-WA	26MHz	±10ppm	±10ppm	10pF	-20°C ~ 70°C
Q 26.0-JXS32-12-10/10-FU-WA-LF	Jauch晶振	JXS32-WA	26MHz	±10ppm	±10ppm	12pF	-20°C ~ 70°C
Q 26.0-JXS32-8-10/10-FU-WA-LF	Jauch晶振	JXS32-WA	26MHz	±10ppm	±10ppm	8pF	-20°C ~ 70°C
Q 26.0-JXS32-9-10/10-FU-WA-LF	Jauch晶振	JXS32-WA	26MHz	±10ppm	±10ppm	9pF	-20°C ~ 70°C
Q 27.12-JXS32-10-10/10-FU-WA-LF	Jauch晶振	JXS32-WA	27.12MHz	±10ppm	±10ppm	10pF	-20°C ~ 70°C
Q 27.12-JXS32-12-10/10-FU-WA-LF	Jauch晶振	JXS32-WA	27.12MHz	±10ppm	±10ppm	12pF	-20°C ~ 70°C
Q 27.12-JXS32-8-10/10-FU-WA-LF	Jauch晶振	JXS32-WA	27.12MHz	±10ppm	±10ppm	8pF	-20°C ~ 70°C
Q 27.12-JXS32-9-10/10-FU-WA-LF	Jauch晶振	JXS32-WA	27.12MHz	±10ppm	±10ppm	9pF	-20°C ~ 70°C
Q 16.0-JXS32-10-10/10-WA-LF	Jauch晶振	JXS32-WA	16MHz	±10ppm	±10ppm	10pF	-20°C ~ 70°C
Q 16.0-JXS32-12-10/10-WA-LF	Jauch晶振	JXS32-WA	16MHz	±10ppm	±10ppm	12pF	-20°C ~ 70°C
Q 16.0-JXS32-8-10/10-WA-LF	Jauch晶振	JXS32-WA	16MHz	±10ppm	±10ppm	8pF	-20°C ~ 70°C
Q 16.0-JXS32-9-10/10-WA-LF	Jauch晶振	JXS32-WA	16MHz	±10ppm	±10ppm	9pF	-20°C ~ 70°C
Q 38.4-JXS32-10-10/10-FU-WA-LF	Jauch晶振	JXS32-WA	38.4MHz	±10ppm	±10ppm	10pF	-20°C ~ 70°C
Q 38.4-JXS32-12-10/10-FU-WA-LF	Jauch晶振	JXS32-WA	38.4MHz	±10ppm	±10ppm	12pF	-20°C ~ 70°C
Q 38.4-JXS32-8-10/10-FU-WA-LF	Jauch晶振	JXS32-WA	38.4MHz	±10ppm	±10ppm	8pF	-20°C ~ 70°C
Q 38.4-JXS32-9-10/10-FU-WA-LF	Jauch晶振	JXS32-WA	38.4MHz	±10ppm	±10ppm	9pF	-20°C ~ 70°C
Q 32.0-JXS32-10-10/10-FU-WA-LF	Jauch晶振	JXS32-WA	32MHz	±10ppm	±10ppm	10pF	-20°C ~ 70°C
Q 32.0-JXS32-12-10/10-FU-WA-LF	Jauch晶振	JXS32-WA	32MHz	±10ppm	±10ppm	12pF	-20°C ~ 70°C
Q 32.0-JXS32-8-10/10-FU-WA-LF	Jauch晶振	JXS32-WA	32MHz	±10ppm	±10ppm	8pF	-20°C ~ 70°C
Q 32.0-JXS32-9-10/10-FU-WA-LF	Jauch晶振	JXS32-WA	32MHz	±10ppm	±10ppm	9pF	-20°C ~ 70°C
Q 0.032768-JTX310-12.5-10-T1-HMR-LF	Jauch晶振	JTX310	32.768kHz	-	±10ppm	12.5pF	-40°C ~ 85°C
Q 0.032768-JTX210-12.5-20-T2-LF	Jauch晶振	JTX210	32.768kHz	-	±20ppm	12.5pF	-40°C ~ 105°C
Q 19.2-JXS32-10-10/15-T1-WA-LF	Jauch晶振	JXS32-WA	19.2MHz	±15ppm	±10ppm	10pF	-40°C ~ 85°C
Q 19.2-JXS32-12-10/15-T1-WA-LF	Jauch晶振	JXS32-WA	19.2MHz	±15ppm	±10ppm	12pF	-40°C ~ 85°C
Q 19.2-JXS32-8-10/15-T1-WA-LF	Jauch晶振	JXS32-WA	19.2MHz	±15ppm	±10ppm	8pF	-40°C ~ 85°C
Q 19.2-JXS32-9-10/15-T1-WA-LF	Jauch晶振	JXS32-WA	19.2MHz	±15ppm	±10ppm	9pF	-40°C ~ 85°C
Q 20.0-JXS32-10-10/15-T1-FU-WA-LF	Jauch晶振	JXS32-WA	20MHz	±15ppm	±10ppm	10pF	-40°C ~ 85°C
Q 20.0-JXS32-12-10/15-T1-FU-WA-LF	Jauch晶振	JXS32-WA	20MHz	±15ppm	±10ppm	12pF	-40°C ~ 85°C
Q 20.0-JXS32-8-10/15-T1-FU-WA-LF	Jauch晶振	JXS32-WA	20MHz	±15ppm	±10ppm	8pF	-40°C ~ 85°C
Q 20.0-JXS32-9-10/15-T1-FU-WA-LF	Jauch晶振	JXS32-WA	20MHz	±15ppm	±10ppm	9pF	-40°C ~ 85°C
Q 24.0-JXS32-10-10/15-T1-FU-WA-LF	Jauch晶振	JXS32-WA	24MHz	±15ppm	±10ppm	10pF	-40°C ~ 85°C
Q 24.0-JXS32-12-10/15-T1-FU-WA-LF	Jauch晶振	JXS32-WA	24MHz	±15ppm	±10ppm	12pF	-40°C ~ 85°C
Q 24.0-JXS32-8-10/15-T1-FU-WA-LF	Jauch晶振	JXS32-WA	24MHz	±15ppm	±10ppm	8pF	-40°C ~ 85°C
Q 24.0-JXS32-9-10/15-T1-FU-WA-LF	Jauch晶振	JXS32-WA	24MHz	±15ppm	±10ppm	9pF	-40°C ~ 85°C
Q 26.0-JXS32-10-10/15-T1-FU-WA-LF	Jauch晶振	JXS32-WA	26MHz	±15ppm	±10ppm	10pF	-40°C ~ 85°C
Q 26.0-JXS32-12-10/15-T1-FU-WA-LF	Jauch晶振	JXS32-WA	26MHz	±15ppm	±10ppm	12pF	-40°C ~ 85°C
Q 26.0-JXS32-8-10/15-T1-FU-WA-LF	Jauch晶振	JXS32-WA	26MHz	±15ppm	±10ppm	8pF	-40°C ~ 85°C
Q 26.0-JXS32-9-10/15-T1-FU-WA-LF	Jauch晶振	JXS32-WA	26MHz	±15ppm	±10ppm	9pF	-40°C ~ 85°C
Q 27.12-JXS32-10-10/15-T1-FU-WA-LF	Jauch晶振	JXS32-WA	27.12MHz	±15ppm	±10ppm	10pF	-40°C ~ 85°C
Q 27.12-JXS32-12-10/15-T1-FU-WA-LF	Jauch晶振	JXS32-WA	27.12MHz	±15ppm	±10ppm	12pF	-40°C ~ 85°C
Q 27.12-JXS32-8-10/15-T1-FU-WA-LF	Jauch晶振	JXS32-WA	27.12MHz	±15ppm	±10ppm	8pF	-40°C ~ 85°C
Q 27.12-JXS32-9-10/15-T1-FU-WA-LF	Jauch晶振	JXS32-WA	27.12MHz	±15ppm	±10ppm	9pF	-40°C ~ 85°C
Q 16.0-JXS32-10-10/15-T1-WA-LF	Jauch晶振	JXS32-WA	16MHz	±15ppm	±10ppm	10pF	-40°C ~ 85°C
Q 16.0-JXS32-12-10/15-T1-WA-LF	Jauch晶振	JXS32-WA	16MHz	±15ppm	±10ppm	12pF	-40°C ~ 85°C
Q 16.0-JXS32-8-10/15-T1-WA-LF	Jauch晶振	JXS32-WA	16MHz	±15ppm	±10ppm	8pF	-40°C ~ 85°C
Q 16.0-JXS32-9-10/15-T1-WA-LF	Jauch晶振	JXS32-WA	16MHz	±15ppm	±10ppm	9pF	-40°C ~ 85°C
Q 38.4-JXS32-10-10/15-T1-FU-WA-LF	Jauch晶振	JXS32-WA	38.4MHz	±15ppm	±10ppm	10pF	-40°C ~ 85°C
Q 38.4-JXS32-12-10/15-T1-FU-WA-LF	Jauch晶振	JXS32-WA	38.4MHz	±15ppm	±10ppm	12pF	-40°C ~ 85°C
Q 38.4-JXS32-8-10/15-T1-FU-WA-LF	Jauch晶振	JXS32-WA	38.4MHz	±15ppm	±10ppm	8pF	-40°C ~ 85°C
Q 38.4-JXS32-9-10/15-T1-FU-WA-LF	Jauch晶振	JXS32-WA	38.4MHz	±15ppm	±10ppm	9pF	-40°C ~ 85°C
Q 32.0-JXS32-10-10/15-T1-FU-WA-LF	Jauch晶振	JXS32-WA	32MHz	±15ppm	±10ppm	10pF	-40°C ~ 85°C
Q 32.0-JXS32-12-10/15-T1-FU-WA-LF	Jauch晶振	JXS32-WA	32MHz	±15ppm	±10ppm	12pF	-40°C ~ 85°C
Q 32.0-JXS32-8-10/15-T1-FU-WA-LF	Jauch晶振	JXS32-WA	32MHz	±15ppm	±10ppm	8pF	-40°C ~ 85°C
Q 32.0-JXS32-9-10/15-T1-FU-WA-LF	Jauch晶振	JXS32-WA	32MHz	±15ppm	±10ppm	9pF	-40°C ~ 85°C
Q 0.032768-JTX310-12.5-10-T2-HMR-LF	Jauch晶振	JTX310	32.768kHz	-	±10ppm	12.5pF	-40°C ~ 105°C
Q 19.2-JXS22-10-10/10-WA-LF	Jauch晶振	JXS22-WA	19.2MHz	±10ppm	±10ppm	10pF	-20°C ~ 70°C
Q 19.2-JXS22-12-10/10-WA-LF	Jauch晶振	JXS22-WA	19.2MHz	±10ppm	±10ppm	12pF	-20°C ~ 70°C
Q 19.2-JXS22-8-10/10-WA-LF	Jauch晶振	JXS22-WA	19.2MHz	±10ppm	±10ppm	8pF	-20°C ~ 70°C
Q 19.2-JXS22-9-10/10-WA-LF	Jauch晶振	JXS22-WA	19.2MHz	±10ppm	±10ppm	9pF	-20°C ~ 70°C
Q 20.0-JXS22-10-10/10-FU-WA-LF	Jauch晶振	JXS22-WA	20MHz	±10ppm	±10ppm	10pF	-20°C ~ 70°C
Q 20.0-JXS22-12-10/10-FU-WA-LF	Jauch晶振	JXS22-WA	20MHz	±10ppm	±10ppm	12pF	-20°C ~ 70°C
Q 20.0-JXS22-8-10/10-FU-WA-LF	Jauch晶振	JXS22-WA	20MHz	±10ppm	±10ppm	8pF	-20°C ~ 70°C
Q 20.0-JXS22-9-10/10-FU-WA-LF	Jauch晶振	JXS22-WA	20MHz	±10ppm	±10ppm	9pF	-20°C ~ 70°C
Q 24.0-JXS22-10-10/10-FU-WA-LF	Jauch晶振	JXS22-WA	24MHz	±10ppm	±10ppm	10pF	-20°C ~ 70°C
Q 24.0-JXS22-12-10/10-FU-WA-LF	Jauch晶振	JXS22-WA	24MHz	±10ppm	±10ppm	12pF	-20°C ~ 70°C
Q 24.0-JXS22-8-10/10-FU-WA-LF	Jauch晶振	JXS22-WA	24MHz	±10ppm	±10ppm	8pF	-20°C ~ 70°C
Q 24.0-JXS22-9-10/10-FU-WA-LF	Jauch晶振	JXS22-WA	24MHz	±10ppm	±10ppm	9pF	-20°C ~ 70°C
Q 26.0-JXS21-10-10/10-FU-WA-LF	Jauch晶振	JXS21-WA	26MHz	±10ppm	±10ppm	10pF	-20°C ~ 70°C
Q 26.0-JXS21-12-10/10-FU-WA-LF	Jauch晶振	JXS21-WA	26MHz	±10ppm	±10ppm	12pF	-20°C ~ 70°C
Q 26.0-JXS21-8-10/10-FU-WA-LF	Jauch晶振	JXS21-WA	26MHz	±10ppm	±10ppm	8pF	-20°C ~ 70°C
Q 26.0-JXS21-9-10/10-FU-WA-LF	Jauch晶振	JXS21-WA	26MHz	±10ppm	±10ppm	9pF	-20°C ~ 70°C
