RUBYQUARTZ TECHNOLOGY LLC

RUBYQUARTZ TECHNOLOGY LLC
Rubyquartz offers customers worldwide the technical expertise of one of the most established and prestigious R&D teams in the frequency components industry.
Products with specifications at the cutting edge of the market demand are designed in the Miami, Fl. headquarters. Manufacturing locations in Florida and China allow the company to satisfy customers’ need to optimize total acquisition cost while sufficient production space is made available for all product families offered. The quality of products offered is one of the key concerns of all Rubyquartz employees and corporate management.
Rubyquartz is offering its products globally, through its direct sales force as well as a network of independent Sales Representatives and Distributors. Customer Service and Technical Support are offered from the Miami, Fl. headquarters.
The wide product range is designed to satisfy the needs of customers in the lecommunications, wireless, industrial, medical, computer, consumer and many other segments of the electronic industry.
Rubyquartz not only delivers products from its standard offering but is always ready to develop special items in order to satisfy the most sophisticated customers’ needs.
We welcome all customers to Rubyquartz Technology!晶振工厂

Rubyquartz科技有限公司

Rubyquartz为全球客户提供频率元件行业最成熟和最负盛名的研发团队之一的技术专业知识。
在佛罗里达州迈阿密的总部设计符合市场需求的产品。在佛罗里达和中国的生产基地使公司能够满足客户的需求，优化总采购成本，同时为所有产品系列提供足够的生产空间。提供的产品质量是所有Rubyquartz员工和企业管理层关注的关键问题之一。
Rubyquartz通过其直接销售队伍以及独立销售代表和分销商网络在全球范围内提供其产品。客户服务和技术支持由佛罗里达州迈阿密总部提供。
广泛的产品范围旨在满足客户在电信，无线，工业，医疗，计算机，消费和电子行业的许多其他细分市场的需求。
Rubyquartz不仅提供标准产品，而且随时准备开发特殊产品，以满足最复杂的客户需求。

我们欢迎所有客户来Rubyquartz科技!

原厂编码	型号	频率	频率稳定度	频率容差	负载电荷	工作温度
RT3215-32.768-12.5-TR	RT3215	32.768 kHz	-	±20ppm	12.5pF	-40°C ~ 85°C
RSM200S-32.768-12.5-TR	RSM200S	32.768 kHz	-	±20ppm	12.5pF	-40°C ~ 85°C
H130B-8.000-18-3030-EXT-TR	H130B	8 MHz	±30ppm	±30ppm	18pF	-40°C ~ 85°C
RSM200S-32.768-12.5-10PPM-NPB	RSM200S	32.768 kHz	-	±10ppm	12.5pF	-40°C ~ 85°C
AS-24.000-18-SMD-TR	AS-SMD	24 MHz	±50ppm	±30ppm	18pF	-20°C ~ 70°C
AS-6.000-12-2020-EXT-SMD-TR	AS-SMD	6 MHz	±20ppm	±20ppm	12pF	-40°C ~ 85°C
RH100-25.000-10-F-3030-EXT-TR	RH100	25 MHz	±30ppm	±30ppm	10pF	-40°C ~ 85°C
RH100-12.000-18-2020-EXT-TR	RH100	12 MHz	±20ppm	±20ppm	18pF	-40°C ~ 85°C
RH100-25.000-13-F-0715-EXT-TR-NS1	RH100	25 MHz	±15ppm	±7ppm	13pF	-40°C ~ 85°C
AS-16.000-18-SMD-TR	AS-SMD	16 MHz	±50ppm	±30ppm	18pF	-20°C ~ 70°C
AS-11.0592-18-SMD-TR	AS-SMD	11.0592 MHz	±50ppm	±30ppm	18pF	-20°C ~ 70°C
RH100-16.000-16-3030-EXT-TR	RH100	16 MHz	±30ppm	±30ppm	16pF	-40°C ~ 85°C
RH100-24.000-9-1015-EXT-TR	RH100	24 MHz	±15ppm	±10ppm	9pF	-40°C ~ 85°C
RH100-32.000-16-F-1015-EXT-TR	RH100	32 MHz	±15ppm	±10ppm	16pF	-40°C ~ 85°C
RH100-40.000-9-F-1010-EXT-TR	RH100	40 MHz	±10ppm	±10ppm	9pF	-40°C ~ 85°C
RH100-48.000-8-F-1015-EXT-TR	RH100	48 MHz	±15ppm	±10ppm	8pF	-40°C ~ 85°C
RH100-12.000-20-2030-TR	RH100	12 MHz	±30ppm	±20ppm	20pF	-20°C ~ 70°C
RH100-11.0592-18-3030-EXT-TR	RH100	11.0592 MHz	±30ppm	±30ppm	18pF	-40°C ~ 85°C
RH100-25.000-18-F-TR	RH100	25 MHz	±100ppm	±100ppm	18pF	-20°C ~ 70°C
RH100-26.000-10-F-1010-EXT-TR	RH100	26 MHz	±10ppm	±10ppm	10pF	-40°C ~ 85°C
RH100-12.000-12-1010-X-TR-NS2	RH100	12 MHz	±10ppm	±10ppm	12pF	-30°C ~ 85°C
RH100-25.000-18-F-2030-EXT-TR	RH100	25 MHz	±30ppm	±20ppm	18pF	-40°C ~ 85°C
RH100-48.000-10-F-1015-EXT-TR	RH100	48 MHz	±15ppm	±10ppm	10pF	-40°C ~ 85°C
R38-32.768-12.5	R38	32.768 kHz	-	±20ppm	12.5pF	-20°C ~ 70°C
R26-32.768-12.5	R26	32.768 kHz	-	±20ppm	12.5pF	-40°C ~ 85°C
RH100-12.000-20-3030-EXT-TR	RH100	12 MHz	±30ppm	±30ppm	20pF	-40°C ~ 85°C
RH100-12.000-18-2020-TR	RH100	12 MHz	±20ppm	±20ppm	18pF	-20°C ~ 70°C
RH100-24.000-18-2030-EXT-TR	RH100	24 MHz	±30ppm	±20ppm	18pF	-40°C ~ 85°C
RH100-12.000-12-1010-EXT-TR	RH100	12 MHz	±10ppm	±10ppm	12pF	-40°C ~ 85°C
RH100-12.000-9-1015-TR-NS1	RH100	12 MHz	±15ppm	±10ppm	9pF	-20°C ~ 70°C
RH100-25.000-16-F-2020-EXT-TR	RH100	25 MHz	±20ppm	±20ppm	16pF	-40°C ~ 85°C
RH100-24.000-8-1010-EXT-TR	RH100	24 MHz	±10ppm	±10ppm	8pF	-40°C ~ 85°C
RH100-25.000-18-F-1010-TR	RH100	25 MHz	±10ppm	±10ppm	18pF	-20°C ~ 70°C
RH100-16.000-8-1010-TR	RH100	16 MHz	±10ppm	±10ppm	8pF	-20°C ~ 70°C
RH100-25.000-10-F-1010-EXT-TR	RH100	25 MHz	±10ppm	±10ppm	10pF	-40°C ~ 85°C
R2520-32.000-8-F-1030-EXT-TR	R2520	32 MHz	±30ppm	±10ppm	8pF	-40°C ~ 85°C
AS-3.579545-18 石英晶振	AS	3.579545 MHz	±50ppm	±30ppm	18pF	-20°C ~ 70°C
AS-4.000-18	AS	4 MHz	±50ppm	±30ppm	18pF	-20°C ~ 70°C
AS-20.000-20	AS	20 MHz	±50ppm	±30ppm	20pF	-20°C ~ 70°C
AS-11.0592-18-EXT	AS	11.0592 MHz	±50ppm	±30ppm	18pF	-40°C ~ 85°C
AS-16.000-20-EXT	AS	16 MHz	±50ppm	±30ppm	20pF	-40°C ~ 85°C
AS-27.000-20-F	AS	27 MHz	±50ppm	±30ppm	20pF	-20°C ~ 70°C
AS-25.000-18-F-EXT	AS	25 MHz	±50ppm	±30ppm	18pF	-40°C ~ 85°C
R2520-12.000-8-1030-EXT-TR	R2520	12 MHz	±30ppm	±10ppm	8pF	-40°C ~ 85°C
RT3215-32.768-9-TR	RT3215	32.768 kHz	-	±20ppm	9pF	-40°C ~ 85°C
RSM200S-32.768-6-TR	RSM200S	32.768 kHz	-	±20ppm	6pF	-40°C ~ 85°C
H130B-16.000-18-3030-EXT-TR	H130B	16 MHz	±30ppm	±30ppm	18pF	-40°C ~ 85°C
H130B-12.000-18-3030-TR	H130B	12 MHz	±30ppm	±30ppm	18pF	-20°C ~ 70°C
H130B-24.000-18-3030-EXT-TR	H130B	24 MHz	±30ppm	±30ppm	18pF	-40°C ~ 85°C
RSE-32.768-12.5-H14-TR	RSE H14	32.768 kHz	-	±50ppm	12.5pF	-20°C ~ 70°C
RH100-8.000-10-1010-EXT-TR	RH100	8 MHz	±10ppm	±10ppm	10pF	-40°C ~ 85°C
H130A-8.000-8-2030-TR	H130A	8 MHz	±30ppm	±20ppm	8pF	-20°C ~ 70°C
RH100-8.000-8-2020-TR	RH100	8 MHz	±20ppm	±20ppm	8pF	-20°C ~ 70°C
RT2012-32.768-6-TR	RT2012	32.768 kHz	-	±50ppm	6pF	-40°C ~ 85°C
RH100-8.000-16-3030-TR-NS1	RH100	8 MHz	±30ppm	±30ppm	16pF	-20°C ~ 70°C
H13-8.000-18-3030-EXT-TR	H13	8 MHz	±30ppm	±30ppm	18pF	-40°C ~ 85°C
AS-4.9152-18-EXT-SMD-TR	AS-SMD	4.9152 MHz	±50ppm	±30ppm	18pF	-40°C ~ 85°C
AS-10.000-20-3030-SMD-TR	AS-SMD	10 MHz	±30ppm	±30ppm	20pF	-20°C ~ 70°C
AS-30.000-10-F-2020-EXT-SMD-TR	AS-SMD	30 MHz	±20ppm	±20ppm	10pF	-40°C ~ 85°C
AS-4.000-18-SMD-TR	AS-SMD	4 MHz	±50ppm	±30ppm	18pF	-20°C ~ 70°C
AS-3.579545-18-SMD-TR	AS-SMD	3.579545 MHz	±50ppm	±30ppm	18pF	-20°C ~ 70°C
AS-13.560-20-SMD-TR	AS-SMD	13.56 MHz	±50ppm	±30ppm	20pF	-20°C ~ 70°C
AS-20.000-16-SMD-TR	AS-SMD	20 MHz	±50ppm	±30ppm	16pF	-20°C ~ 70°C
AS-7.3728-20-EXT-SMD-TR	AS-SMD	7.3728 MHz	±50ppm	±30ppm	20pF	-40°C ~ 85°C
AS-7.3728-18-SMD-TR	AS-SMD	7.3728 MHz	±50ppm	±30ppm	18pF	-20°C ~ 70°C
RH100-13.560-10-1020-EXT-TR	RH100	13.56 MHz	±20ppm	±10ppm	10pF	-40°C ~ 85°C
RH100-26.000-18-F-2030-EXT-TR	RH100	26 MHz	±30ppm	±20ppm	18pF	-40°C ~ 85°C
RH100-24.000-9-1010-TR	RH100	24 MHz	±10ppm	±10ppm	9pF	-20°C ~ 70°C
RH100-24.000-8-1530-EXT-TR	RH100	24 MHz	±30ppm	±15ppm	8pF	-40°C ~ 85°C
RH100-10.000-10-5050-TR	RH100	10 MHz	±50ppm	±50ppm	10pF	-20°C ~ 70°C
RH100-10.000-8-2020-TR	RH100	10 MHz	±20ppm	±20ppm	8pF	-20°C ~ 70°C
RH100-24.000-20-3050-EXT-TR	RH100	24 MHz	±50ppm	±30ppm	20pF	-40°C ~ 85°C
RH100-32.000-12-F-3030-TR	RH100	32 MHz	±30ppm	±30ppm	12pF	-20°C ~ 70°C
RH100-50.000-12-F-1010-TR	RH100	50 MHz	±10ppm	±10ppm	12pF	-20°C ~ 70°C
RH100-50.000-10-F-1015-EXT-TR	RH100	50 MHz	±15ppm	±10ppm	10pF	-40°C ~ 85°C
RH100-16.000-9-1010-TR	RH100	16 MHz	±10ppm	±10ppm	9pF	-20°C ~ 70°C
RH100-25.000-6-F-1010-TR	RH100	25 MHz	±10ppm	±10ppm	6pF	-20°C ~ 70°C
RH100-25.000-8-F-1010-TR	RH100	25 MHz	±10ppm	±10ppm	8pF	-20°C ~ 70°C
RH100-26.000-12-F-1010-EXT-TR	RH100	26 MHz	±10ppm	±10ppm	12pF	-40°C ~ 85°C
RH100-32.000-10-F-1010-TR	RH100	32 MHz	±10ppm	±10ppm	10pF	-20°C ~ 70°C
AS-8.000-20-SMD-TR	AS-SMD	8 MHz	±50ppm	±30ppm	20pF	-20°C ~ 70°C
R2520-32.000-10-F-1010-TR-B1B	R2520	32 MHz	±10ppm	±10ppm	10pF	-10°C ~ 60°C
AS-18.432-20	AS	18.432 MHz	±50ppm	±30ppm	20pF	-20°C ~ 70°C
R2520-24.000-10-1010-TR-NS4	R2520	24 MHz	±10ppm	±10ppm	10pF	-10°C ~ 60°C
RT3215-32.768-7-TR	RT3215	32.768 kHz	-	±20ppm	7pF	-40°C ~ 85°C
RH100-8.000-20-3050-EXT-TR	RH100	8 MHz	±50ppm	±30ppm	20pF	-40°C ~ 85°C
R2016-32.000-10-F-1020-EXT-TR	R2016	32 MHz	±20ppm	±10ppm	10pF	-40°C ~ 85°C
R2016-32.000-12-F-1010-EXT-TR	R2016	32 MHz	±10ppm	±10ppm	12pF	-40°C ~ 85°C
R2016-32.000-10-F-1010-TR-B1B_REVB	R2016	32 MHz	±10ppm	±10ppm	10pF	-30°C ~ 70°C
H130B-25.000-12-F-EXT-TR	H130B	25 MHz	±50ppm	±50ppm	12pF	-40°C ~ 85°C
H130B-25.000-20-F-3030-TR	H130B	25 MHz	±30ppm	±30ppm	20pF	-20°C ~ 70°C
H130B-18.432-18-EXT-TR	H130B	18.432 MHz	±50ppm	±50ppm	18pF	-40°C ~ 85°C
R2016-27.120-10-F-1010-TR-NS4	R2016	27.12 MHz	±10ppm	±10ppm	10pF	-10°C ~ 60°C
H130A-24.000-18-2030-EXT-TR	H130A	24 MHz	±30ppm	±20ppm	18pF	-40°C ~ 85°C
