遥遥领先的proXO振荡器组合来自Renesas Oscillator

Renesas Electronics Corporation , a premier supplier of advanced semiconductor solutions, expanded its robust timing solutions portfolio with the ProXO+ family of compact, ultra-low noise, temperature-controlled clock oscillators. The high-accuracy, high-frequency, differential oscillators are best suited for fiber optic transceiver modules, accelerator cards, smart NIC cards, and networking equipment applications.Oscillator Crystal

“The ProXO+ family delivers on all counts, offering tight frequency stability, great jitter performance, and high output frequency, which are critical features for communications, cloud and compute markets,” said Bobby Matinpour, Vice President of Timing Products at Renesas. “The ProXO+ family’s high level of programmability also enables the use of a single device for numerous designs, simplifying the BOM, sourcing, and inventory management.”
Key Features of the ProXO+ Family
Frequency stability ±3 ppm from -40C to +85C temperature range
Programmable frequencies up to 2.1 GHz
135fs typical phase jitter (12 KHz-20 MHz)
3.2 x 2.5 mm in an 8-pin plastic package
In addition to the new ProXO+ family, Renesas is expanding the popular original ProXO XF 2.5 x 2.0 mm device to include two new industry-standard 3.2 x 2.5 mm and 5.0 x 3.2 mm plastic packages.
The ProXO+ family can be combined with Renesas’ complementary clock buffers, power, and microcontroller offerings to create comprehensive solutions for a variety of applications, such as the Xilinx Kintex-7 Power and Timing, the CC-Link IE TSN, and the System on Module (SoM) Solution with RZ/G2E. Renesas’ Winning Combinations are vetted solutions engineered to help customers accelerate designs and get to market faster.

Renesas provides the industry’s broadest timing portfolio to support the complete clock tree. As the market leader in silicon timing with a long history of bringing cutting-edge technologies to the markets, Renesas offers the only “one-stop-shop” for timing solutions, offering expertise and products from full-featured system solutions to simple clock tree building-block devices.晶振工厂

原厂编码	生产商品牌	型号	频率	输出	电源电压	频率容差
XFP536625.000000I	Renesas晶振	XF	625 MHz	LVPECL	3.3V	±25ppm
XFN516100.000000I	Renesas晶振	XF	100 MHz	HCSL	1.8V	±25ppm
XFL526125.000000I	Renesas晶振	XF	125 MHz	LVDS	2.5V	±25ppm
XFL235837.500000K	Renesas晶振	XF	837.5 MHz	LVDS	3.3V	±50ppm
XFP235156.250000K	Renesas晶振	XF	156.25 MHz	LVPECL	3.3V	±50ppm
XFN336100.000000I	Renesas晶振	XF	100 MHz	HCSL	3.3V	±25ppm
XFP336312.500000I	Renesas晶振	XF	312.5 MHz	LVPECL	3.3V	±25ppm
XFL336156.250000I	Renesas晶振	XF	156.25 MHz	LVDS	3.3V	±25ppm
XFP236148.500000I	Renesas晶振	XF	148.5 MHz	LVPECL	3.3V	±25ppm
XFN236100.000000I	Renesas晶振	XF	100 MHz	HCSL	3.3V	±25ppm
XFL516100.000000I	Renesas晶振	XF	100 MHz	LVDS	1.8V	±25ppm
XFL536125.000000I	Renesas晶振	XF	125 MHz	LVDS	3.3V	±25ppm
XFL336032.768000I	Renesas晶振	XF	32.768 MHz	LVDS	3.3V	±25ppm
XFL316125.000000I	Renesas晶振	XF	125 MHz	LVDS	1.8V	±25ppm
XFP526156.250000I	Renesas晶振	XF	156.25 MHz	LVPECL	2.5V	±25ppm
XFP536025.000000I	Renesas晶振	XF	25 MHz	LVPECL	3.3V	±25ppm
XFL336333.330000I	Renesas晶振	XF	333.33 MHz	LVDS	3.3V	±25ppm
XFL336032.000000I	Renesas晶振	XF	32 MHz	LVDS	3.3V	±25ppm
XFL526032.000000I	Renesas晶振	XF	32 MHz	LVDS	2.5V	±25ppm
XFL336333.333333I	Renesas晶振	XF	333.333333 MHz	LVDS	3.3V	±25ppm
XFL336125.000000I	Renesas晶振	XF	125 MHz	LVDS	3.3V	±25ppm
XFL516500.000000I	Renesas晶振	XF	500 MHz	LVDS	1.8V	±25ppm
XFL316300.000000I	Renesas晶振	XF	300 MHz	LVDS	1.8V	±25ppm
XFL336148.425824I	Renesas晶振	XF	148.425824 MHz	LVDS	3.3V	±25ppm
XFL336161.132812I	Renesas晶振	XF	161.132812 MHz	LVDS	3.3V	±25ppm
XFP336161.132812I	Renesas晶振	XF	161.132812 MHz	LVPECL	3.3V	±25ppm
XFL536026.000000I	Renesas晶振	XF	26 MHz	LVDS	3.3V	±25ppm
XFL536100.000000I	Renesas晶振	XF	100 MHz	LVDS	3.3V	±25ppm
XFL336096.000000I	Renesas晶振	XF	96 MHz	LVDS	3.3V	±25ppm
XFL336048.000000I	Renesas晶振	XF	48 MHz	LVDS	3.3V	±25ppm
XFL336333.333000I	Renesas晶振	XF	333.333 MHz	LVDS	3.3V	±25ppm
XFP536156.250000I	Renesas晶振	XF	156.25 MHz	LVPECL	3.3V	±25ppm
XFL336450.000000I	Renesas晶振	XF	450 MHz	LVDS	3.3V	±25ppm
XFC516025.000000I	Renesas晶振	XF	25 MHz	CML	1.8V	±25ppm
XFL316270.000000I	Renesas晶振	XF	270 MHz	LVDS	1.8V	±25ppm
XFL336025.000000I	Renesas晶振	XF	25 MHz	LVDS	3.3V	±25ppm
XFL236644.531250I	Renesas晶振	XF	644.53125 MHz	LVDS	3.3V	±25ppm
XFP216025.000000I	Renesas晶振	XF	25 MHz	LVPECL	1.8V	±25ppm
XFL236830.078125I	Renesas晶振	XF	830.078125 MHz	LVDS	3.3V	±25ppm
XFL226156.250000I	Renesas晶振	XF	156.25 MHz	LVDS	2.5V	±25ppm
XFL236156.250000I	Renesas晶振	XF	156.25 MHz	LVDS	3.3V	±25ppm
XFN236156.250000I	Renesas晶振	XF	156.25 MHz	HCSL	3.3V	±25ppm
XFN216100.000000I	Renesas晶振	XF	100 MHz	HCSL	1.8V	±25ppm
XFL236108.000000I	Renesas晶振	XF	108 MHz	LVDS	3.3V	±25ppm
XFL216156.250000I	Renesas晶振	XF	156.25 MHz	LVDS	1.8V	±25ppm
XFP236161.132812I	Renesas晶振	XF	161.132812 MHz	LVPECL	3.3V	±25ppm
XFP226156.250000I	Renesas晶振	XF	156.25 MHz	LVPECL	2.5V	±25ppm
XFP216625.000000I	Renesas晶振	XF	625 MHz	LVPECL	1.8V	±25ppm
XFL236148.500000I	Renesas晶振	XF	148.5 MHz	LVDS	3.3V	±25ppm
XFN216161.132812I	Renesas晶振	XF	161.132812 MHz	HCSL	1.8V	±25ppm
XFP216156.250000I	Renesas晶振	XF	156.25 MHz	LVPECL	1.8V	±25ppm
XFN236025.000000I	Renesas晶振	XF	25 MHz	HCSL	3.3V	±25ppm
XFC226156.250000I	Renesas晶振	XF	156.25 MHz	CML	2.5V	±25ppm
XFL226026.000000I	Renesas晶振	XF	26 MHz	LVDS	2.5V	±25ppm
XFL216625.000000I	Renesas晶振	XF	625 MHz	LVDS	1.8V	±25ppm
XFL216397.770000I	Renesas晶振	XF	397.77 MHz	LVDS	1.8V	±25ppm
XFL216078.125000I	Renesas晶振	XF	78.125 MHz	LVDS	1.8V	±25ppm
XFC216837.500000I	Renesas晶振	XF	837.5 MHz	CML	1.8V	±25ppm
XFL536040.000000I	Renesas晶振	XF	40 MHz	LVDS	3.3V	±25ppm
XFP336048.000000I	Renesas晶振	XF	48 MHz	LVPECL	3.3V	±25ppm
XFL516156.250000I	Renesas晶振	XF	156.25 MHz	LVDS	1.8V	±25ppm
XFL536200.000000I	Renesas晶振	XF	200 MHz	LVDS	3.3V	±25ppm
XFL525100.000000I	Renesas晶振	XF	100 MHz	LVDS	2.5V	±50ppm
XFL516245.000000I	Renesas晶振	XF	245 MHz	LVDS	1.8V	±25ppm
XFP336156.253906I	Renesas晶振	XF	156.253906 MHz	LVPECL	3.3V	±25ppm
XFL336165.000000I	Renesas晶振	XF	165 MHz	LVDS	3.3V	±25ppm
XFL536156.250000I	Renesas晶振	XF	156.25 MHz	LVDS	3.3V	±25ppm
XFL526100.000000I	Renesas晶振	XF	100 MHz	LVDS	2.5V	±25ppm
XFL336161.132813I	Renesas晶振	XF	161.132813 MHz	LVDS	3.3V	±25ppm
