X1C048000FK1H-HX超小型晶振,加高环保晶振,遥遥领先的北斗卫星晶振

TH-1 890

X1C048000FK1H-HX超小型晶振,加高环保晶振,遥遥领先的北斗卫星晶振,台湾HELE晶振公司，台产晶振，特点:超小型尺寸，外形低调(1.65x1.25x0.4)mm高精度、可靠性高，热量高抵抗针对设计空间有限的智能手机应用程序、小型化无线模块设备、RFID应用程序和其他基于消费者的产品的优化解决方案。加高晶振，高质量晶振，高精度晶振，超小型晶振，1612晶振，数码相机晶振，智能手机晶振，智能穿戴设备晶振，笔记本电脑晶振，环保无铅晶振，无源晶振，四脚晶振，贴片晶振，石英晶振。

TH-2 890

X1C048000FK1H-HX超小型晶振,加高环保晶振,遥遥领先的北斗卫星晶振

频率	48.000000MHz
型号	HSX111SA
频率容差	+/-30 ppm at 25deg.C +/-3deg.C
等效串联电阻	80 ohms Max. / SERIES
储存温度范围	-40 deg.C To +85 deg.C
工作温度范围	-20 deg.C To +70 deg.C
温度漂移	+/-30 ppm-20 deg.C To +70 deg.C
负载电容	20.0 pF
驱动电平	10 uW(100uW Max.)
分流电容	2.0pF Max.
工作模式	Fundamental
老化	Less than +/- 3 ppm/Year

X1C048000FK1H-HX超小型晶振,加高环保晶振,遥遥领先的北斗卫星晶振

原厂编码	生产商	型号	频率	频率稳定度	频率容差	负载电容	工作温度
X2C025000DZ1H-U	加高晶振	HSX211S	25 MHz	±20ppm	±20ppm	6pF	-40°C ~ 105°C
X2C032000BA1H-HZ	加高晶振	HSX211S	32 MHz	±15ppm	±10ppm	10pF	-
X2C024000DZ1H-HU	加高晶振	HSX211S	24 MHz	±20ppm	±20ppm	6pF	-40°C ~ 105°C
X2C016000B81H-R	加高晶振	HSX211S	16 MHz	±10ppm	±10ppm	8pF	-30°C ~ 85°C
X2C026000BC1H-Z	加高晶振	HSX211S	26 MHz	±10ppm	±10ppm	12pF	-30°C ~ 85°C
X1C032000B81H-HR	加高晶振	HSX111S	32 MHz	±10ppm	±10ppm	8pF	-
X1C024000B81H-HV	加高晶振	HSX111S	24 MHz	±30ppm	±10ppm	8pF	-
X2C048000L71HH-CEHZ	加高晶振	HSX211S	48 MHz	±14ppm	±8ppm	11.1pF	-
X1R038400B81HA-CEHPZ	加高晶振	HSX111SR	38.4 MHz	±10ppm	-	8pF	-
X2U026000B81HBZ-DHPZ	加高晶振	HSX211SR	26 MHz	-	±10ppm	8pF	-40°C ~ 105°C
X2U019200BZ1H-CEHQZ	加高晶振	HSX211SR	19.2 MHz	-	±10ppm	7pF	-40°C ~ 105°C
X2U038400B81H-EPQZ	加高晶振	HSX211SR	38.4 MHz	-	±10ppm	8pF	-30°C ~ 85°C
X1R052000B81HZ-DEHPZ	加高晶振	HSX111SR	52 MHz	±10ppm	-	8pF	-40°C ~ 105°C
X12A040000BZ1H-HZ	加高晶振	HSX1210A	40 MHz	±10ppm	±12ppm	6pF	-20°C ~ 85°C
X12A032000B81H-HZ	加高晶振	HSX1210A	32 MHz	±10ppm	±10ppm	8pF	-30°C ~ 85°C
X1C026000B81H-V	加高晶振	HSX111SA	26 MHz	±10ppm	±20ppm	26pF	-20°C ~ 80°C
X1C032000B81H-HU	加高晶振	HSX111SA	32 MHz	±10ppm	±10ppm	8pF	-20°C ~ 80°C
X1C048000FK1H-HX	加高晶振	HSX111SA	48 MHz	±30ppm	±30ppm	20pF	-20°C ~ 80°C
X2C016000B81H-HPU	加高晶振	HSX211S	16 MHz	±10ppm	±20ppm	8pF	-40°C ~ 85°C
X2C016000B91H-R_C254270	加高晶振	HSX211S	16 MHz	±10ppm	±10ppm	9pF	-40°C ~ 85°C
X2C024000B91H-HZ	加高晶振	HSX211S	24 MHz	±10ppm	±10ppm	9pF	-40°C ~ 85°C
X2C024000BA1H	加高晶振	HSX211S	24 MHz	±10ppm	±30ppm	10pF	-40°C ~ 85°C
X2C024000FA1H-X	加高晶振	HSX211S	24 MHz	±30ppm	±30ppm	10pF	-40°C ~ 85°C
X2C024000B71H-V	加高晶振	HSX211S	24 MHz	±10ppm	±30ppm	12.5pF	-40°C ~ 85°C
X2C026000B91H-V	加高晶振	HSX211S	26 MHz	±10ppm	±15ppm	9pF	-20°C ~ 70°C
X2C027120FA1H-HV	加高晶振	HSX211S	27.12 MHz	±30ppm	±30ppm	10pF	-30°C ~ 85°C
X2C032000B81H-HS	加高晶振	HSX211S	32 MHz	±10ppm	±15ppm	8pF	-30°C ~ 85°C
X2C032000BA1HA-U	加高晶振	HSX211S	32 MHz	±10ppm	±20ppm	10pF	-40°C ~ 85°C
X2C032000BC1H-R	加高晶振	HSX211S	32 MHz	±10ppm	±10ppm	12pF	-20°C ~ 70°C
X2C037400BG1H-U	加高晶振	HSX211S	37.4 MHz	±10ppm	±10ppm	16pF	-20°C ~ 70°C
X2C038400BA1H-HZ	加高晶振	HSX211S	38.4 MHz	±10ppm	±10ppm	10pF	-30°C ~ 85°C
X2C040000B91HA-Z	加高晶振	HSX211S	40 MHz	±10ppm	±10ppm	9pF	-30°C ~ 85°C
X2C048000L71H-CEHZ	加高晶振	HSX211S	48 MHz	±8ppm	±12ppm	7.8pF	-30°C ~ 85°C
X2C048000BA1H-HZ	加高晶振	HSX211S	48 MHz	±10ppm	±10ppm	10pF	-30°C ~ 85°C
X2B050000BC1H-V	加高晶振	HSX221S	50 MHz	±10ppm	±30ppm	12pF	-40°C ~ 85°C
X1C026000B81H-V	加高晶振	HSX111SA	26 MHz	±10ppm	±20ppm	8pF	-20°C ~ 80°C
X1C026000BC1H-HZ	加高晶振	HSX111SA	26 MHz	±10ppm	±10ppm	12pF	-20°C ~ 85°C
X1C032000B81H-HU	加高晶振	HSX111SA	32 MHz	±10ppm	±10ppm	8pF	-20°C ~ 70°C
X2B050000BC1H-V	加高晶振	HSX221S	50 MHz	±10ppm	±30ppm	12pF	-40°C ~ 85°C
X2C016000B81H-R	加高晶振	HSX221S	16 MHz	±10ppm	±10ppm	8pF	-20°C ~ 75°C
X2C016000B91H-R	加高晶振	HSX211S	16 MHz	±10ppm	±10ppm	9pF	-20°C ~ 75°C
X2C016000BC1H-Z	加高晶振	HSX211S	16 MHz	±10ppm	±20ppm	12pF	-20°C ~ 85°C
X2C024000B71H-V	加高晶振	HSX211S	24 MHz	±10ppm	±30ppm	12.5pF	-40°C ~ 85°C
X2C024000B91H-HZ	加高晶振	HSX211S	24 MHz	±10ppm	±10ppm	9pF	-40°C ~ 85°C
X2C024000BA1H	加高晶振	HSX211S	24 MHz	±10ppm	±30ppm	10pF	-10°C ~ 60°C
X2C032000BA1HA-U	加高晶振	HSX211S	32 MHz	±10ppm	±20ppm	10pF	-40°C ~ 85°C
X2C037400BG1H-U	加高晶振	HSX211S	37.4 MHz	±10ppm	±10ppm	16pF	-20°C ~ 70°C
X2C040000B91HA-Z	加高晶振	HSX211S	40 MHz	±10ppm	±10ppm	9pF	-30°C ~ 85°C
X2C048000L71H-CEHZ	加高晶振	HSX211S	48 MHz	±8ppm	±12ppm	7.8pF	-30°C ~ 85°C
