12.80108|32.768KHz|12.5pF|Geyer晶振|圆柱插件晶振

产品简介

12.80108|32.768KHz|12.5pF|Geyer晶振|圆柱插件晶振,Geyer晶振,KX-38T无源晶振,圆柱插件晶振,12.80108晶振,3.0*8.0mm晶振,石英晶体谐振器,二脚插件晶振,频率32.768KHz,负载12.5pF,工作温度-40~85°C,频率容差20ppm,高可靠性晶振,小体积晶振,无铅环保晶振,数字电表晶振,家用电器遥控器晶振,储存卡晶振,平板电脑晶振.

产品详情

TH-1 890 Ja-1

12.80108|32.768KHz|12.5pF|Geyer晶振|圆柱插件晶振,Geyer晶振,KX-38T无源晶振,圆柱插件晶振,12.80108晶振,3.0*8.0mm晶振,石英晶体谐振器,二脚插件晶振,频率32.768KHz,负载12.5pF,工作温度-40~85°C,频率容差20ppm,高可靠性晶振,小体积晶振,无铅环保晶振,数字电表晶振,家用电器遥控器晶振,储存卡晶振,平板电脑晶振.

TH-2 890 TH--TC2

12.80108|32.768KHz|12.5pF|Geyer晶振|圆柱插件晶振规格表

part no.	12.80108
model	KX-38T
frequency range	32.768KHz
mode	fundamental
operating temperature	-40~+85℃
frequency toleranceat +25°C	土20 ppm
temperature tolerance	-0.042 ppm / °C² typ.
load capacitance CL	12.5 pF
shunt capacitance C0max.	1.3 pF
series resistance R1 (ESR) max.	30 kOhm
aging at +25°℃ (first year) max.	±3 ppm
drive level	0.02 mW max., 0.01 mW typ
solderable	wave soldering max. 10 s 260°C following reflow soldering only up to 240°C
